Pompa Pelumasan Minyak Berat
POMPA PELUMASAN MINYAK BERAT
Pompa Pelumasan Minyak Berat / Pompa Pelumasan Minyak Berat VOP - W2, VOP - W3
| MODEL | Kapasitas aliran (c.c/rew) |
Tipe Dapat Disetel | Pengembalian oli eksternal | Rentang tekanan kgf/cm² |
BERAT kgf | |||
|---|---|---|---|---|---|---|---|---|
| VOP-W | -* | 1500 | 1800 | -RV | -D | -* | Model | BERAT |
| VOP-W2 | 16 | 24 | 28.8 | None RV |
D : Pengembalian Oli Eksternal | 30 kgf/cm² | W216 | 6.5 |
| 26 | 39 | 46.9 | W220 | 7.0 | ||||
| VOP-W3 | 20 | 30 | 36 | W336 | 8.5 | |||
| 39 | 58.5 | 70.2 | W339 | 10 | ||||
VOP-W Kecepatan–Laju Aliran
| Model | Kapasitas aliran (c.c/rew) | Tekanan Maks kgf/cm² |
Kecepatan Maks (rpm) | ||
|---|---|---|---|---|---|
| Kecepatan Putaran ( rpm ) | |||||
| cc/rev | 1500 | 1800 | |||
| VOP-W216 | 16 | 24 | 28.8 | 30 | 1800 |
| VOP-W220 | 20 | 30 | 36 | ||
| VOP-W326 | 26 | 39 | 46.9 | ||
| VOP-W339 | 39 | 58.5 | 70.2 | ||
