Variable Displacement Vane Pumps

VARIABLE DISPLACEMENT VANE PUMPS

Variable Displacement Vane Pumps / Low-Pressure Double Pump / VVPE . VVPEA

FEATURES

Double variable displacement vane pumps built into one single baby, with a common driving shaft endble driving two indepen-dent pumps to produce two branchs of oil flow system which avoid to interfere each other.
Requires only one single-shaft, uses single electric motor.
Space saving for easier installation and maintenance.
Closed circuit to achieve lower level.

MODEL	Mounting	Shaft delivery side of pump	Shaft end pump pressure kgf/cm²	Cover delivery side of pump	Secondary pump pressure kgf/cm²	Design number
*-	*	*	*	-*	*	- *
VVPE-	F : Flange L : Foot	8 12 15 20	A : 08~18 kgf/cm² B : 15~35 kgf/cm² C : 30~55 kgf/cm² D : 50~70 kgf/cm²	8 12 15 20	A : 08~18 kgf/cm² B : 15~35 kgf/cm² C : 30~55 kgf/cm² D : 50~70 kgf/cm²	10 : Parallel Key 9T : Spline
VVPEA-	F : Flange L : Foot	15 20 24		15 20 24
VVPE-	F : Flange L : Foot	25 30 40		25 30 40
VVPE-	F : Flange L : Foot	47		47

Weight / Model		VVPE-08-24	VVPE-25-47
WEIGHT kgf ( lbs )	F : Flange	9.2 kg	15.7 kg
WEIGHT kgf ( lbs )	L : Foot	10.7 kg	18.8 kg

Speed MAX : 1800 r / min
Speed MIN : 800 r / min
