VARIABLE DISPLACEMENT VANE PUMPS
Variable Displacement Vane Pumps / Low-Pressure Variable Displacement Pumps / VPFE - F08 ~ 47
| MODEL | Mounting | Standard delivery l/min ( 1800 rpm ) |
Adjusting pressure range kgf/cm² |
Design number | Weight kgf | |
|---|---|---|---|---|---|---|
| VPFE- | F | * | * | - * | F : Flange | L : Foot |
| VPFE- | F : Flange Flange |
08 12 |
A : 08~18 kgf/cm² B : 15~35 kgf/cm² C : 30~55 kgf/cm² D : 50~70 kgf/cm² |
X：15.875 7T : Spline 9T : Spline |
4.9 kg | / |
| 15 20 24 |
6.3 kg | / | ||||
| 25 30 40 |
10 : Parallel Key 9T : Spline |
9 kg | / | |||
| 47 | 10 : Parallel Key | |||||
Speed MAX : 1800 r / min
Speed MIN : 800 r / min
