Heavy Oil Lubrication Pumps
HVAVY OIL LUBRICATION PUMPS
Heavy Oil Lubrication Pumps / Heavy Oil Lubrication Pumps VOP - W2, VOP - W3
| MODEL | Delivery capacity (c.c/rew) |
Adjustable type |
External oil return |
Pressure range kgf/cm² |
Weight kgf | |||
|---|---|---|---|---|---|---|---|---|
| VOP-W | -* | 1500 | 1800 | -RV | -D | -* | Model | Weight |
| VOP-W2 | 16 | 24 | 28.8 | None RV |
D : External Return Oil | 30 kgf/cm² | W216 | 6.5 |
| 26 | 39 | 46.9 | W220 | 7.0 | ||||
| VOP-W3 | 20 | 30 | 36 | W336 | 8.5 | |||
| 39 | 58.5 | 70.2 | W339 | 10 | ||||
VOP-W Speed–Flow Rate
| Model | Delivery capacity (c.c/rew) | Max. pressure kgf/cm² |
Max. speed (rpm) |
||
|---|---|---|---|---|---|
| Speed of Rotation ( rpm ) | |||||
| cc/rev | 1500 | 1800 | |||
| VOP-W216 | 16 | 24 | 28.8 | 30 | 1800 |
| VOP-W220 | 20 | 30 | 36 | ||
| VOP-W326 | 26 | 39 | 46.9 | ||
| VOP-W339 | 39 | 58.5 | 70.2 | ||
