Variable Displacement Vane Pumps

VARIABLE DISPLACEMENT VANE PUMPS

Variable Displacement Vane Pumps / Low-Pressure Variable Vane + Gear Pump / VGPE + PA

FEATURES

The system design engineers a low cost, high working pressure, simple structure, easily-maintain and installation
High flow capacity and saving horsepower and small size provide economic space
Maximum working pressure 210 kgf/cm² ( 3000psi )
Low noise level, endurance and heat generated is much less
Variable displacement pump and gear pump one are assembled with the same shaft directly

MODEL	Mounting	Standard delivery l/min ( 1800 rpm )	Adjusting pressure range kgf/cm²	Gear pump	Design number	Weight kgf
VGPE-	*	*	*	-PA	- *	F : Flange	L : Foot
VGPE-	F : Flange L : Foot	25 30 40	A : 08~18 kgf/cm² B : 15~35 kgf/cm² C : 30~55 kgf/cm² D : 50~70 kgf/cm²	HGP-2A 2~12	10 : Parallel Key 9T : Spline	9.3kg	12.5 kg
VGPE-	F : Flange L : Foot	47		HGP-2A 2~12	10 : Parallel Key	9.3kg	12.5 kg

Weight excludes rear gear pump
Gear pump shaft diameter: Ø12.5
Speed MAX : 1800 r / min
Speed MIN : 800 r / min
