Variable Displacement Vane Pumps

VARIABLE DISPLACEMENT VANE PUMPS

Variable Displacement Vane Pumps / High-Pressure Variable + Gear Pump / VDC + PA

FEATURES

The system design engineers a low cost, high working pressure, simple structure, easily-maintain and installation
High flow capacity and saving horsepower and small size provide economic space
Maximum working pressure 210 kgf/cm² ( 3000psi )
Low noise level, endurance and heat generated is much less
Variable displacement pump and gear pump one are assembled with the same shaft directly

MODEL	Adjustable type	Mounting	Standard delivery l/min ( 1800rpm )	Adjusting pressure range kgf/cm²	Gear pump	Design number
VDC-	*	-*	*	*	-PA	- *
VDC-1	A : Normal B : Addition C : Unload	F : Flange L : Foot	20 25 30 40	A : 15~35 kgf/cm² B : 20~70 kgf/cm² C : 50~105 kgf/cm² D : 70~140 kgf/cm²	HGP -2A 2~12	20 : Parallel Key 9T : Spline 9TS : Without Sleeve
VDC-2			54			20 : Parallel Key
			70	MAX Pressure : 105 kgf/cm²
			86	MAX Pressure : 70 kgf/cm²

Weight / Model		VDC-1A.1B	VDC-2A.2B	VDC-1C	VDC-2C
WEIGHT kgf ( lbs )	F : Flange	10.7 kg	26.5 kg	11.4 kg	27.5 kg
WEIGHT kgf ( lbs )	L : Foot	13.9 kg	33.2 kg	14.7 kg	34.2 kg

Weight excludes rear gear pump
Speed MAX : 1800 r / min
Speed MIN : 800 r / min
